| A | Total length | 6,470 mm | |
| B | Total length without bucket | 5,610 mm | |
| C | Bucket pivot point (to center of axle) | 1,200 mm | |
| D | Wheel base | 2,660 mm | |
| E | Rear overhang | 1,520 mm | |
| F | Height with cab | 3,060 mm | |
| H | Seat height | 1,940 mm | |
| J | Total working height | 4,780 mm | |
| K | Bucket pivot point (max. lift height) | 3,820 mm | |
| L | Load-over height | 3,550 mm | |
| M | Dumping height | 2,860 mm | |
| N | Reach (at M) | 970 mm | |
| O | Digging depth | 136 mm | |
| P | Total width | 2,390 mm | |
| Q | Track width | 1,820 mm | |
| S | Ground clearance | 500 mm | |
| T | Maximum radius | 5,370 mm | |
| U | Radius on the outer edge | 4,900 mm | |
| V | Inner radius | 2,450 mm | |
| W | Articulation angle | 40 ° | |
| X | Rollback angle at max. lift height | 61 ° | |
| Y | Dumping angle | 45 ° | |
| Z | Rollback angle on ground | 45 ° | |
| - | 500 / 70 R24 Michelin BIBLOAD ET40 |
WL95
